This tool analyses the thermal performance of building façades directly from a DXF geometry file. No account required.

• U-value — computes the overall thermal transmittance of the façade, accounting for surfaces and all thermal bridges.
• Thermal bridges — quantifies linear (ψ) and point (χ) thermal bridge contributions to total heat loss.
• Heat flux breakdown — shows the split of heat losses between surfaces, linear bridges, and point bridges.
• Visual results — interactive colour-coded diagram of the façade with selectable result views and tabular output.

Compatible with EN 12631, NFRC 100, and similar façade thermal calculation methods.

Draw the façade elevation in any CAD tool and export as .DXF in line with the used calculation method (EN 12631, NFRC 100…)

There are three types of entities that can be drawn:

• Area-based heat loss — draw each area as a closed polyline or a set of closed lines.
• Linear thermal bridges — draw a line or polyline representing a linear heat loss. If the linear heat loss corresponds to the perimeter of a closed polyline, there is no need to redraw it.
• Point thermal bridges — draw point heat losses as points in the DXF.
• Units — draw in millimetres. The tool auto-detects common DXF units.

Keep the geometry flat (2 D). Only the XY plane is used for thermal calculations.
